SmartTec's Swing Gates are designed to provide secure, elegant, and fully automated or manual access control for residential, commercial, and industrial entrances. These gates operate by swinging inward or outward on strong hinges, offering a classic design combined with modern motorized automation.
SmartTec's Single leaf Swing Gate are mostly used for pedestrian opening Engineered with heavy-duty steel construction and advanced automation systems, Smart Tec swing gates deliver smooth movement, long service life, and reliable performance. They are ideal for villas, housing societies, factories, warehouses, office complexes, and institutional buildings where both security and appearance are important.
Available in single-leaf and double-leaf configurations, our swing gates can be customized according to entrance width, architectural design, and operational requirements.
| Parameter | Specification |
|---|---|
| Product Type | Motorized Swing Gate |
| Structure | Heavy-duty MS Steel / Aluminium Fabrication |
| Operation | Inward / Outward Swinging |
| Configuration | Single Leaf / Double Leaf |
| Hinge Type | Heavy-duty Bearing Hinges |
| Finish | Powder Coated / Painted |
| Opening Angle | Up to 90° / 120° (as per Design) |
| Installation | Residential / Commercial / Industrial |
| Application | Indoor & Outdoor |
| Parameter | Specification |
|---|---|
| Motor Type | Linear Actuator / Arm Type Motor |
| Motor Power | 0.5 HP – 1 HP (depending on gate size) |
| Power Supply | 230V Single Phase |
| Operating Speed | Adjustable |
| Duty Cycle | Moderate to High-frequency Usage |
| Locking System | Electromechanical Locking |
| Manual Override | Key Release During Power Failure |
| Protection Rating | IP54 / IP55 |
| Parameter | Specification |
|---|---|
| Control Type | Automatic Control Panel |
| Operation Modes | Auto / Manual |
| Functions | Open / Stop / Close |
| Remote Operation | RF Remote Control |
| Safety Inputs | Photocell / Safety Sensor Compatible |
| Protection | Overload & Short-Circuit Protection |
| Panel Enclosure | Weather-Resistant Metal Housing |
| Emergency Stop | Included |
