sales@smarttec.inSmart Tec Self Repairing High Speed Doors are specially designed for high-traffic industrial areas where accidental impacts are common.
These doors automatically Repair themselves into the side guides after collision, reducing downtime and eliminating frequent maintenance of door.
Ideal for warehouses, logistics hubs, food processing units, cold storage, pharmaceuticals, and clean rooms, this door ensures continuous workflow, safety, and energy efficiency even in demanding environments.
Possible obstacles will immediately be detected as the Smart Tec Self Repairable High Speed Door comes with a well-tested and field proven combination of 2 safety devices with high IP grade. In the unlikely event of a crash, the fully flexible curtain and the soft bottom are designed not to cause any harm. The self-reinserting function of the curtain reduces the risk of downtime after a crash and makes this door the perfect solution for a smooth and trouble-free process flow!
An accessible manual release system allows you to quickly open the door in case of an emergency.
| Parameter | Specification |
|---|---|
| Door Type | Self Repairable High Speed Door |
| Curtain Material | High-strength flexible PVC |
| Curtain Thickness | 0.9 mm / 1.2 mm (Optional up to 1.5 mm) |
| Self-Repair System | Zipper-type automatic re-insertion system |
| Opening Speed | 0.8 – 2.5 m/s (Adjustable) |
| Closing Speed | 0.8 – 1.5 m/s (Adjustable) |
| Wind Resistance | Flexible wind bars (as required) |
| Transparent Vision Panel | 1.2 mm clear PVC window |
| Bottom Seal | Flexible soft bottom edge |
| Airtight Sealing | Yes |
| Application | Indoor Industrial Use |
| Operating Cycle | High-frequency usage |
| Parameter | Specification |
|---|---|
| Motor Type | Servo Motor |
| Motor Power | 0.75 kW / 1.5kW / 3 kW |
| Control System | Intelligent Servo Controller |
| Positioning System | Encoder-based precise control |
| Operation Modes | Manual / Automatic |
| Auto-Close Timer | Adjustable |
| Push Button | Dead-man control, IP65 |
| Power Supply | Single Phase 200–240V |
| Control Panel | Compact industrial control box |
| Safety Component | Details |
|---|---|
| IR Photoelectric Sensor | IP67 obstacle detection |
| Safety Edge | Airbag type bottom sensor |
| Emergency Stop | Yes |
| Soft Bottom Design | Prevents injury & damage |
| Impact Recovery | Curtain automatically reinserts after impact |
| Compliance | CE, TUV & EN 13241-1 |
Smart Tec Self Repairable High Speed Doors are equipped with intelligent automation features to ensure smooth and reliable operation in demanding industrial environments::
Safety is an essential aspect of Smart Tec Self Repairable High Speed Doors, designed to ensure reliable and secure operation in industrial environments:
